XWORKS Wisecat Flex 700W 80+ Platinum Modular PSU (ENP-7760B)

The Wisecat Flex 700W 80+ Platinum Modular PSU is based on the ENP-7760B PSU design. The PSU rated output power is 700W. It is a high efficiency design with 80 Plus Platinum certification. It has a fully modular design with black silicone cables. Thi The PSU supports the following connectors: 1x 14-to-24-Pin motherboard connector 1x 4+4-Pin EPS connector 2x 6+2-Pin PCIE connector 2x SATA connector 1x MOLEX connector Technical specifications: Product No: ENP-7760B Max. DC Output: 700W Load Range: +3.3V: 15A MAX +5V: 15A MAX +5VSB: 2.5A MAX +12V: 58A MAX -12V: 0.3A MAX Input Voltage: 100-240V Efficiency: 90%~94% @ 20%~100% loading Certification: 80 PLUS Platinum Dimension: 40 x 80 x 161 mm Pinout:
